BenQ PX9510 - Timing Chart and 3 D Support

English
64
Timing chart
The following table shows compatible signal types, their resolution and frequency refresh rates.
Horizontal: 15kHz, 31kHz to 90 kHz, Vertical: 50 Hz to 85 Hz
PC timing
Signal Type Resolution
Frame
Rate
Computer 2 Computer 1
DVI-D
HDMI
HDBaseT
Video /
S- Video
RGBHV YUV RGBHV YUV RGB YUV
PC
640x480 60 V V V V V
640x480 75 V V V V V
640x480 85 V V V V V
800x600 60 V V V V V
800x600 75 V V V V V
800x600 85 V V V V V
848x480 60 V V V V V
1024x768 60 V V V V V
1024x768 75 V V V V V
1024x768 85 V V V V V
1024x768 120 V V V V V
1024x768 RB 120 V V V V V
1280x720 60 V V V V V
1280x720 120 V V V V V
1280x768 60 V V V V V
1280x800 60 V V V V V
1280x800 RB 120 V V V V V
1280x960 60 V V V V V
1280x1024 60 V V V V V
1280x1024 75 V V V V V
1280x1024 85 V V V V V
1440x900 60 V V V V V
1400X1050 60 V V V V V
1600x1200 60 V V V V V
1680x1050 59.94 V V V V V
1920X1200 RB 60 V V V V V
Video
NTSC (M)
(3.58, 4.43)
59.94 V
PAL (B,G,H,I) 50 V
PAL (N) 50 V
PAL (M) 60 V
SECAM (M)
(4.25/4.4)
50 V
SDTV
1440x480i 60 V V V (HDMI)
1440x576i 50 V V V (HDMI)
480i 59.94 V V V
576i 50 V V V
EDTV
480p 59.94 V V V V V V V V
576p 50 V V V V V V V V
1080i 50 V V V V V V
1080i 60 V V V V V V
720p 50 V V V V V V V V
720p 60 V V V V V V V V
1080p 24 V V V V V V V V
1080p 25 V V V V V V V V
1080p 29.97 V V V V V V V V
1080p 30 V V V V V V V V
1080p 50 V V V V V V V V
1080p 60 V V V V V V V V
