22 VIEWING ACTUATOR HISTORY
22.1
ACTIVITY
Select change in the MENU and turn to OK to confirm.
Select activity in the CHANGE menu and turn to OK to
confirm.
Select number of starts or running time to view total figures
since the actuator was manufactured. The system also includes
a separate counter which can be reset by the user.
Select total to view total number of starts.
To reset the partial counter, select reset partial and then
choose yes or no (this option is only displayed when the user is
in the change menu).
starts / 12 hour: this data relates to the num-
ber of times the actuator has started during
the previous 12 hours and tells the user about recent service.
This is particularly useful when trying to establish whether the
actuator has been subjected to excessive use when performing modulating actions.
handwheel action: indicates whether the handwheel has been used since the last time a motorised
movement was made. (changes are only registered if they exceed 10% of travel).
22.2 ALARMS
Alarms are used to pinpoint the source of malfunctions. They are not permanent and are deactivated
when the fault is cleared. A blinking black square is shownon the screen to indicate that an alarm
has been activated. To read alarms: Select check in the MENU and turn to OK to confirm .
Select alarms in the menu CHECK menu and turn to OK to confirm.
Use the right-hand selector to scroll through any active alarms.
To check settings without making
changes, select check instead
of change in the menu.
ACTIVITY
return
number of starts
running time
starts last 12h
handwheel action
return
NUMBER OF
STARTS
total
partial
reset partial
List Details
locked motor open
locked motor close
jammed valve
torque sensor
position sensor
direc of rot open
direc of rot close
overtravel
config. memory
activity memory
base memory
excess starts
lost phase
lost signal
thermal overload
pumping
24V auxiliary
battery low
no alarm
Details
Motor immobilised in open direction
Motor immobilised in close direction
Max torque reached during operation
Torque sensor fault
Position sensor fault
Opening direction of rotation anomaly
Closing direction of rotation anomaly
Position overshoot >5% after motor cut off
Stored configuration data error
Stored activity data fault
Base memory fault
Start-up rate exceeds average for class of actuator.
See criteria for class in §23
This alarms never causes the actuator to stop operating.
Phase missing on 3-phase supply
4-20 mA signal lost (if positioner option active)
Motor thermal switch tripped
Actuator hunting action detected
Auxiliary power supply fault for external circuits (terminals 6-7)
If battery option used, the battery needs to be changed
