PROBLEM CAUSE REMEDY
The actuator rotates in the wrong direction
Incorrect configuration
Check closing direction in the position sub-menu under change to determine whether closing action clockwise or anti-clockwise..
Motor wiring changed and motor rotates in reverse direction (when motor replaced)
Comply with wiring tags when changing the motor. If in doubt, check motor rotates the right way. The motor’s direction of rotation can be reversed by changing over wires 2 and 3 on the motor terminal strip inside the control box.
Menu settings cannot be changed Changes cannot be made in the
check menu
Go to the change menu. Some settings are view-only.
The actuator operates in local mode, but not in remote.
Local / remote selector on remote or off (stop)
Switch the local / remote selector to the local position.
Dry contact control: no voltage between terminals 6 and 7
Ensure there is a jumper between terminals 5 and 6 on the client terminal strip. Check whether a “24V auxiliary” alarm is present
Voltage control: voltage not adapted to input
Check voltage control connections: 10 - 55 volts: terminal 5 55 to 250 volts: terminal 4
Changes made not applied. No modifications made during
change process. Changes have to be confirmed before they are saved
After making changes, run back through the menus using return and OK until the display shows: (change ok?) Turn to OK to confirm and save the changes made
Actuator jerky operation during movement
Timing function settings made The user sets this option in the timer menu to increase the actuator’s movement time.
Handwheel action not detected Handwheel action detected since
last motorized movement provided actuator remains switched on. The system only reports movements exceeding 10% of trave
Repeat detection under correct conditions.
Excess starts alarm displayed
INTELLI+ monitors the number of starts performed during the previous 12 hours and checks this number against the actuator’s operating class.
This alarm does not restrict operation of the actuator. It just indicates that the actuator is being used intensively. The alarm will cleared when the number of starts returns to the intended frequency for the system concerned.
