10 Maintenance and Repair LB 470 Level
56925BA2 Rev. 03, 11/2017
10.1 Replacing of Fuses
Danger to life from electric shock!
Replacing of fuses may only be carried out by a qualified electrician.
Please adhere to the relevant safety regulations.
Installation/maintenance may only be carried out if the device has been
de-energised.
Only open the device when free of voltage.
In case of an electric shock, carry out first aid measures and immediately call an
emergency service.
Damage to the device! Short circuit!
The EVU can be damaged if incorrect fuses are used.
Only use fuses which correspond to the fuses on the circuit board of the
module.
Fuses:
• Master EVU 250V 1A T (5x20 mm)
• Master EVU 250V TR5 T80mA (Ø 8,5 mm)
• Slave module 250V 315mA T (5x20 mm)
