Berthold Duo Xpert - Assignment terminals master;slave plug

5 Electric Installation LB 470 Level
54
56925BA2 Rev. 03, 11/2017
NOTICE
Note the specification relating to Protective earth and equipotential bonding
in chapter 5.1.4.
NOTICE
Only cable that is suitable for connection to the corresponding terminals may
be used. For further specifications, see appendix “Technical Information”.
5.6.1 84BAssignment terminals master/slave plug
Signal
Pin
TxD 41
RxD 42
RTS 43
GND 44
Fig.
25 Assignment Terminals master/slave plug
