Berthold Duo Xpert - Unpacking;Scope of Delivery; Installation variants

4 Installation LB 470 Level
30
56925BA2 Rev. 03, 11/2017
4.3 Installation variants
The modules can be installed either in wall housings (Fig. 12) or 19" subracks (Fig.
13).
Installation variants wall housing
Fig.
12 Installation variants wall housing
Installation
variant
Connection
Components
Wall housing
Terminal panel master 2 Master (Fig. 12, item 2)
Terminal panel master/slave
1 Master, 3 Slaves (Fig. 12
,
item 1)
Clamp blocks 2 Master (Fig. 12, item 2)
