BestCode Next Series 8 Technical Manual October 2022 Page 90 of 290
Solvent Filter (31-0021-01) Replacement
Be familiar with proper safety information for handling fluids.
Procedure Time: 15 minutes
1. Remove the Makeup SmartFill cup
Instructions here
2. Locate the Solvent Filter
(31-0021-01)
3. Remove the Makeup Tank form
the fluidic compartment
4. Remove the Makeup pickup
from the Makeup Tank
5. Disconnect the Makeup feed
tube from the Main Ink
Manifold
