BestCode Next Series 8 Technical Manual October 2022 Page 257 of 290
Stage 1:Empty Tank, Ready to Be Commissioned
Stage 2, 2 Bottles Added Into the Tank
Stage 3, Solvent Low Warning
Stage 4, 2 bottles added after Low Warning
To commission the Solvent Tank, We begin with an Empty Solvent Tank (Stage 1 Image). 2 x 946ml bottles of Solvent is
added to the Tank (Stage 2 Image). The machine will use a minimal amount of Solvent to Prime the System, less than
50ml.
The Add 1 Bottle warning occurs at 1700ml.
The Solvent Low warning occurs at 600ml (Stage 3 image).
The difference then between commissioning the system and the Add 1 Bottle warning is 242ml. This effect will give the
appearance that the machine is quickly comsuming solvent, which is a misconstrued fact.
When the Solvent Low warning goes active, add 2 bottles of Solvent consumption testing (Stage 4 Image). It will be a
tank total volume of 2492ml. It can be found that the time from 2 bottles added to the next Low Warning will be in line
with the listed consumption charts.
