BestCode Next Series 8 Technical Manual October 2022 Page 282 of 290
Installing 44-5051-01: Factory Air Dryer-Enclosure/Printhead Pressurization
Be familiar with proper safety information for electronic service
routines listed in Technical Manual V1.13 on pages iv-vii
Procedure Time: 45 Minutes
1. Remove the CPU board from the printer.
2. Remove the Makeup Fill cup
3. Remove the Fan by removing the 4 self-tapping
screws. May require T25 or Phillips #2
