4
118
7Nm
M6x35
7Nm
M6x20
ENGINE REASSEMBLY IN THE VEHICLE
∙ Grease the rear fastener and tighten the screws
at the indicated torque values.
∙ Apply the seat.
ATTENTION!
Disconnecting the mixer tube from the intake
manifold could cause air to get into the tube it-
self. To avoid any lubrication problems with the
thermal unit and crankshaft, use fuel with a 1%
blend for the first fill-up.
Use the oil recommended on page 112 in the
"Recommended lubricants and liquids" table.
∙ Apply the seat.
∙ Reapply the engine guard plate with the two
fixing screws, once the motorcycle is removed
from the stand. Tighten to the specified torque.
