1
16
23
25
24
ENGINE REMOVAL FROM VEHICLE
• Remove the swingarm pin. Pull the entire
wheel/swingarm unit outwards.
• Extract the engine from the frame and apply
it to the specific stand, code 3625132 000,
using the specific front fixing bracket, code
026140030 000.
• Remove the shock-absorber pin 23.
• Remove the gear lever 24 and the engine pins
25.
