2
30
7
9
9
10
ENGINE DISASSEMBLY
Removal of centrifugal control lever.
Extract the centrifugal control lever 7 together with
the two thrust washers 9.
Extract the complete centrifugal unit 10.
Extraction of centrifugal unit.
