2
37
4
A
9
2
1
4
10
11
ENGINE DISASSEMBLY
Using a pair of pliers, pull the end A of the spring 4
out of the housing hole on the crankcase and move
it to a resting position by turning it anti-clockwise.
Turn the shaft anti-clockwise and pull it off together
with the sleeve 9, the spring 10 and the thrust
washer 11.
Releasing spring from crankcase.
Extraction of shaft from crankcase.
Complete pedal kickstart shaft.
