3
69
C
ENGINE CHECKS AND ASSEMBLY
Turn the spring clockwise until it fits into the spe-
cific hole C.
Insertion of kickstart return spring.
Insert in the slot on the protruding segment of
the secondary shaft: the circlip 18, the rose-petal
17, the idler wheel 4 followed by the rose-petal
17 and the circlip 18 as shown in the figure.
Kickstart device unit coupled to the crankcase.
