3
95
6
A
7
ENGINE CHECKS AND ASSEMBLY
Repeat the operation on the opposite side using
one M6 screw.
Remove screw 6 that keeps the left side bearings
and the booster in their housing.
Apply one M5 screw on control unit side and pull
outwards.
After extracting the boosters and relevant pin, ex-
tract the valve pin 7 by pushing it with a metal
cylinder A and then extract valve 8.
