3
97
3
4
10Nm
5
10Nm
ENGINE CHECKS AND ASSEMBLY
Apply the left side booster unit complete with pin
and bearings in its seat: pin 3 must be inserted in
the specific slot in the valve.
Apply the right side booster unit in its seat.
Apply screws 4 and 5 complete with washer after
applying medium-resistance threadlocker and
tighten at the specified torque.
