D:Attach(2143)MiddleBack,ontheoutsideoftheassemblytoboth(2153)Postswith2(H2)1/4x2”HexBolts
(withlockwasher,atwasherandt-nut).(g.10.3)
E: Makesuretheassemblyissquarethentightenallboltsandattach(2143)MiddleBacktoeach(2153)Post
with2(S15)#8x1-3/4”WoodScrews.(g.10.3)
F:Attheendsof(2143)MiddleBackand(2120)FloorFrontBackplace(2112)SLPost,asshowning.10.3.
Attach(2112)SLPostto(2123)BackFloorwith1(H5)1/4x4-1/2”HexBolt(withlockwasher,atwasherand
t-nut)andto(2143)MiddleBackwith1(H4)1/4x4”HexBolt(withlockwasher,atwasherandt-nut)inthetop
holeand1(S7)#12x2”PanScrew(withatwasher)inthebottomhole.(g.10.3)
G:Attach(2112)SLPostto(2120)FloorFrontBackwith2(S4)#8x3”WoodScrews.(g.10.3)
HardwareWood Parts
1 x Middle Back 1 x 5 x 65-5/8”
1 x SL Post 2 x 4 x 32-1/2”
2143
2112
Step 10: Back Wall Assembly
Part 2
2123
2153
1/4”lock
washer
1/4”at
washer
1/4”
t-nut
Outside View
2143
Fig. 10.3
H2
H2
S15
H5
S7
H4
2120
2112
with3/16”
atwasher
1/4”lock
washer
1/4”at
washer
1/4”
t-nut
2 x #8 x 1-3/4” Wood Screw
1 x #12 x 2” Pan Screw (3/16” at washer)
2 x #8 x 3” Wood Screw
2 x 1/4 x 2” Hex Bolt
(1/4” lock washer, 1/4” at washer, 1/4” t-nut)
1 x 1/4 x 4” Hex Bolt
(1/4” lock washer, 1/4” at washer, 1/4” t-nut)
1 x 1/4 x 4-1/2” Hex Bolt
(1/4” lock washer, 1/4” at washer, 1/4” t-nut)
H2
S15
H4
S7
H5
S4
S4
