Step 3: Swing Beam Assembly
Make sure triangle is
tight against beam
WARNING: For your child’s
safety, orientate the swing hangers
as shown to ensure your swing will
have proper swing motion when
installed. Failure to do so could
result in premature failure of the
swing hanger or swing chain.
A:Inthemiddleholesof(1825)
BackBeaminstall2Bolt-ThruSwing
Hangers(g.3.1)makingsurethe
swinghangersareorientedinthe
directionshowning.3.4tomaintain
properswingmotion.
B:Intheendholesof(1826)FrontBeaminstall2
Bolt-ThruSwingHangers(g.3.1)makingsurethe
swinghangersareorientedinthedirectionshownin
g.3.4tomaintainproperswingmotion.
4 x 1/4 x 5-1/2” Hex Bolt
(1/4” at washer, 1/4” lock washer, 1/4” t-nut)
4 x 5/16 x 1-1/2” Hex Bolt
(5/16” at washer, 5/16” lock washer, 5/16” t-nut)
H7
G1
1 x Bolt-Thru Swing Hangers (pkg of 4)
1 x Triangle Plate (pkg of 4)
1 x Front Beam 2 x 6 x 83-5/8”
1 x Back Beam 2 x 6 x 83-5/8”
1826
1825
Fig. 3.4
Bolt-ThruSwingHangers
Wood Parts
Hardware
Other Parts
Fig. 3.1
C: Attach1TrianglePlatetothe
endsofeach(1826)FrontBeam
and(1825)BackBeamusing1
(G1)5/16x1-1/2”HexBolt(with
lockwasher,atwasherand
t-nut)pertriangleplateinthehole
indicateding.3.2&3.3.Correct
hole usage is very important.
Triangle
Plates
Important!
Swing End
(With Overhang)
G1
H7
H7
1826
Important!
Fort End Side
(No Overhang)
Fig. 3.2
Fig. 3.3
D:Attach1(H7)1/4x5-1/2”Hex
Bolt(withlockwasher,atwasher
andt-nut)totheendsofeach(1826)
FrontBeamand(1825)BackBeam.
Theboltsdonotattachtoanything,
butMUSTbeinstalledtothebeams
topreventsplittingandcheckingof
wood.(g.3.2&3.3)
Swing End
(With Overhang)
Fort End Side
(No Overhang)
1825
G1
H7
G1
H7
G1
1/4”Flat
Washer
1/4”Lock
Washer
1/4”T-Nut
5/16”Flat
Washer
5/16”Lock
Washer
5/16”T-Nut
1826
1825
Bolt-ThruSwingHangers
Makesureholesarealigned.
