Big Backyard F23073C - Floor Assembly

To Next Page

To Previous Page

 41  support@solowavedesign.com

HardwareWood Parts

Fig. 13.1

4 x #8 x 3” Wood Screw

1 x Floor Joist 2 x 3 x 65-5/8”

2142

Step 13: Floor Assembly

Part 1

A: Loosenthetopboltandremovethebottomboltin(2130)SWMount.Donotdiscardthesebolts,youwill

re-installthemafter(2142)FloorJoistisattached.

B:Flushtothebottomofboth(2126)SWFloorand(2122)SLFloorEndattach(2142)FloorJoistwith2(S4)

#8x3”WoodScrewsperend(g.13.1)

C:Re-installtheboltin(2130)SWMountandtightenbothbolts.(g.13.1)

2122

Slide Wall

2126

Swing Wall

2106

2130

x4

2142
