Step 33: Assemble Spiral Wave Slide
A:Assemblethetopandbottomsectionsusingthetongueandgrooveasaguide.Pushtogetheruntilsnaps
engage.(g.33.133.2&33.3)
B:Completesubassemblybysecuringsectionswith2(S8)#12x3/4”PanScrewspersectioninthemiddleholes
and2(S6)#12x1”PanScrewspersectionintheoutsideholes.Seeg.33.2foraccuratescrewplacement.
Hardware
2 x #12 x 3/4” Pan Screw
2 x #12 x 1” Pan Screw
S8
Fig. 33.1
Other Parts
1 x Top Section
1 x Bottom Section
TopSection
Fig. 33.2
Fig. 33.3
BottomSection
Snaps
S6
S8
S6
