Step 20: Lower Slide Wall Assembly
Part 1
Hardware
Wood Parts
4 x #12 x 2” Pan Screw
3 x #8 x 2-1/2” Wood Screw
S7
1 x Cafe Top 5/4 x 6 x 40-7/8”
1 x Cafe Support 2 x 2 x 40-3/8”
2141
S3
2129
A:Place(2129)CafeSupportushtotheshortnotchedoutextensionof(2141)CafeTop,asshowning.
20.1,andattachusing4(S7)#12x2”PanScrews.
B: PlaceCafeTopAssemblyagainstboth(2153)PostsontheSlideWallsideso(2141)CafeTopislevelwith
(2131)FrontTableTop.MakesureCafeTopAssemblyislevelthenattachto(2102)FrontTableSupportand
both(2153)Postswith3(S3)#8x2-1/2”WoodScrews.(g.20.2and20.3)
Fig. 20.1
Flush
2141
2129
Flush
S7
Flush
S3
2153
2141
Thisholenotused
2131
2153
2129
Slide Wall
Fig. 20.2
Fig. 20.3
ShortNotch
2102
(hiddenbehindboard)
