Big Backyard F23073C - Access Ladder; Rockwall Assembly

 20  support@solowavedesign.com
1 x Access Rail Right 2 x 3 x 56-1/8”
1 x Access Rail Left 2 x 3 x 56-1/8”
4 x Tennon Dowel 1-1/8 x 15-7/8”
1578
2101
2100
Fig. 2.1
Wood Parts Hardware
Step 2: Access Ladder / Rockwall Assembly
Part 1
Pre-drill all pilot holes using a 1/8” drill bit before installing wood screws.
A:Insert4(1578)1-1/8x15-7/8”Dowelsinto(2100)AccessRailRightand(2101)AccessRailLeftasshownin
g.2.1.
B:Makesureshoulderofdowelisagainsteachrailbeforepre-drillingpilotholes.Drill1/8”pilotholesthroughthe
railsandintothedowelstopreventsplitting.(g.2.1)
C:Attach(1578)1-1/8x15-7/8”Dowelstobothrailswith2(S2)#8x1-1/2”WoodScrewsperdowel.(g.2.1)
8 x #8 x 1-1/2” Wood Screw
1578
2101
Left Side
Right Side
S2
2100
S2
x8
1578
