Step 28: Attach Swing Assembly to Fort
Hardware
1 x 5/16 x 4-1/2” Hex Bolt
(5/16” lock washer, 5/16” at washer, 5/16” t-nut)
1 x 5/16 x 2” Hex Bolt
(5/16” at washer x 2, 5/16” lock nut)
Fig. 28.2
G5
A:AttachSwingAssemblyfromStep5to(2130)SWMountwith1(G5)5/16x4-1/2”HexBolt(withlock
washer,atwasherandt-nut)and1(G8)5/16x2”HexBolt(with2atwashersand1locknut)asshowning.
28.1and28.2.
G8
G5
Fig. 28.1
5/16”Lock
Washer
5/16”Flat
Washer
5/16”
T-Nut
5/16”
Locknut
5/16”
Flat
Washer
2130
G8
