Step 6: Door Assembly
Part 1
3 x Door Siding 3/8 x 3-1/2 x 11-3/8”
1 x Door Siding Top 3/8 x 3-1/2 x 11-3/8”
Wood Parts
1 x Door Side Right 1-1/4 x 3 x 40-1/8”
1 x Door Side Left 1-1/4 x 3 x 40-1/8”
2 x Door Cross 1/2 x 3-3/8 x 15-7/16”
1 x Door Arch 1/2 x 4-1/2 x 15-7/16”
Hardware
18 x #8 x 1-1/8” Wood Screw
10 x #8 x 7/8” Truss Screw
2057
2053
2052
2058
2051
2050
S1
A: Place1(2052)DoorCrossushtothebottomandoutsideedgesof(2057)DoorSideRightand(2058)Door
SideLeft.(g.6.1)
B: Placethesecond(2052)DoorCrossinthemiddlenotchesof(2057)DoorSideRightand(2058)DoorSide
Left,ushtotheoutsideedges.(g.6.1)
C: Place(2053)DoorArchtighttothetopnotchesof(2057)DoorSideRightand(2058)DoorSideLeft,ushto
theoutsideedges.(g.6.1)
D: Makesureassemblyissquarethenattachtop,middleandbottomboardswith6(S1)#8x1-1/8”Wood
Screwsperboard.(g.6.1)
E: Startingtighttothebottom(2052)DoorCross,andworkingup,evenlyspace3(2051)DoorSidingthen1
(2050)DoorSidingToptighttotheinsideedgesof(2057)DoorSideRightand(2058)DoorSideLeft.(2050)
DoorSidingTopshouldsittighttothebottomof(2052)DoorCross.Attacheach(2051)DoorSidingwith2(S0)
#8x7/8”TrussScrewsperboardand(2050)DoorSidingTopwith4(S0)#8x7/8”TrussScrews.(g.6.1)
S0
Fig. 6.1
2058
Fig. 6.2
S1
x6
S0
2053
Flushandtight
S1
S1
x6
2050
2052
2052
2051
x10
2057
x6
