A:Place1(4909)SWBlockcentredon(2137)SLUprightandattachusing2(S3)#8x2-1/2”Wood
Screws.Theangledendof(2137)SLUprightisatthetopoftheboard.(g.34.1)
1 x SL Upright 2 x 3 x 48-1/2”
1 x SW Block 5/4 x 4 x 3-1/2”
HardwareWood Parts
2 x #8 x 2-1/2” Wood Screw
2137
4909
Fig. 34.1
S3
S3
2137
4909
Step 34: Slide Support Assembly
Part 1
Notice
angledend
