Step 18: Attach Roof to Fort
Part 1
A: WithtwohelpersplacetheRoofAssembly,fromStep8,onthefortateach(2153)Post,asshowning.
18.1.
B: Attacheach(2132)RoofSupportLeftand(2146)RoofSupportRighttoeach(2153)Postwith1(H6)1/4x
4-3/4”HexBolt(withlockwasher,atwasherandt-nut)ineachpost.(g.18.1and18.2)
Fig. 18.1
2153
Fig. 18.2
2153
2153
1/4”
t-nut
1/4”lock
washer
1/4”at
washer
4 x 1/4 x 4-3/4” Hex Bolt
(1/4” lock washer, 1/4” at washer, 1/4” t-nut)
H6
H6
Hardware
2146
2132
2146
