Big Backyard F23073C - Attach Ground Stakes

 43  support@solowavedesign.com
A:Drive1(0318)GroundStake10-1/2”intothegroundon(2157)GroundSWSideat(0369)LowerDiagonal
and1ontheSlideWallSidetightto(2153)PostontheBackWallasshowning.14.1.Attachusing2(S3)
#8x2-1/2”WoodScrewspergroundstake.(g.14.2)
Wood Parts
Hardware
Fig. 14.1
4 x #8 x 2-1/2” Wood Screw2 x Ground Stake 1-1/4 x 1-1/2 x 14”
0318
S3
Step 14: Attach Ground Stakes
MOVE FORT TO FINAL LOCATION. FINAL LOCATION MUST BE LEVEL GROUND.
WARNING: To prevent tipping and avoid potential injury, stakes must
be driven 10-1/2” into ground. Digging or driving stakes can be dangerous
if you do not check rst for underground wiring, cables or gas lines.
2153
10-1/2”IntoGround
Fig. 14.2
0369
Swing Side
S3
Front Wall
Back Wall
2157
0318
Slide Wall
