Big Backyard F23073C - Attach Glider and Swings

 68  support@solowavedesign.com
A: ConnecttheassembledGlidertotheGliderHangerspreviouslyinstalled.(g.31.1)
B: Attach2BeltSwingstotheBolt-ThruSwingHangers.(g.31.1)
Use an extra
Flat W asher
If Bolt protrudes
beyond T-Nut
WARNING: Check entire play centre
for bolts protruding beyond T-Nuts. Use
extra washers to eliminate this condition.
Step 31: Attach Glider and Swings
Glider
Belt Swings
2 x Belt Swings
Other Parts
Fig. 31.1
