Step 18: Attach Roof to Fort
Part 2
C: TotheinsideofeachRoofSupportAssemblyattach1PeakDetailwith8(S8)#12x3/4”PanScrews(with
atwasher)perassembly.(g.18.3and18.4)
D: FlushtothebottomofeachPeakDetailattach1(2121)GableBottomtoeachRoofSupportAssemblywith
2(S7)#12x2”PanScrewsperboard.(g.18.5and18.6)
4 x #12 x 2” Pan Screw
16 x #12 x 3/4” Pan Screw (1/4” at washer)
Other Parts
2 x Peak Detail
HardwareWood Parts
2 x Gable Bottom 5/4 x 3 x 35-7/8”
2121
Fig. 18.3
2121
Fig. 18.4
Fig. 18.5
Fig. 18.6
x8perPeakDetail
with1/4”atwasher
S8
PeakDetail
Inside View
S7
PeakDetail
Tight
x4
2121
S8
S7
