1 x Ladder Top 5/4 x 3 x 35-1/4”
1 x Rock Rail 2 x 3 x 56-1/8”
Fig. 2.2
Fig. 2.3
2117
2111
Step 2: Access Ladder / Rockwall Assembly
Part 2
D: TurntheAccessLadderAssemblyoverthenplace(2117)RockRailonthegroundnextto(2101)AccessRail
Leftsoitmatchestheorientationoftheothertworailsasshowning.2.2.
E:Flushtotheoutsideedgesof(2100)AccessRailRightand(2117)RockRailandtotheanglededgesofall
threerailsattach(2111)LadderToptotopofAccessLadderassemblyand(2117)RockRailusing3(S15)#8x
1-3/4”WoodScrews.Noticethattheholesintheboardaretowardsthebottom.(g.2.2and2.3)
Wood Parts Hardware
3 x #8 x 1-3/4” Wood Screw
S15
2117
S15
2111
2100
LadderTopushto
thisedgeandtoend
S15
2101
2111
2100
RockRailushto
endofLadderTop.
Noticeholelocation
