Big Backyard F23073C - Page 22

 22  support@solowavedesign.com
2 x Top Bottom Rockwall 1 x 6 x 19-3/4”
4 x CE Rock Board 1 x 6 x 19-3/4”
4 x CE Rock Board 1 x 6 x 19-3/4”
Step 2: Access Ladder / Rockwall Assembly
Part 3
Fig. 2.4
Wood Parts Hardware
2149
0630
0631
F:Place1(2149)TopBottomRockwallattopoftheassembly,tightto(2111)LadderTopand1(2149)Top
BottomRockwallatthebottomoftheassemblyasshowning.2.4.Thenplace4(0630)CERockBoardsand4
(0631)CERockBoardsasshowning.2.4.Donotscrewboardsdownyet.Rockholesaretobestaggeredso
theydonotformastraightlineandareatthetopoftheboards.Note: Rock Boards are to be ush to outside
edges of (2101) Access Rail Left and (2117) Rock Rail. (g. 2.4)
G:Makesureallboardsttogethersnuglyandtheassemblyissquare,thenattachboth(2149)TopBottom
Rockwalls,followedbythe(0630)and(0631)CERockBoardsusing4(S2)#8x1-1/2”WoodScrewsperboard.
(g.2.4)
40 x #8 x 1-1/2” Wood Screw
Tight
S2
S2
x4perboard
2149
0631
0630
2111
Bottom
Top
2101
2117
