Step 2: Access Ladder / Rockwall Assembly
Part 4
8 x 1/4 x 1-1/4 Pan Bolt
(1/4” lock washer, 3/16” at washer & 1/4” barrel nut)
8 x #8 x 1” Pan Screw
PB2
Hardware
Other Parts
8 x Rocks (green/yellow)
S10
H:Alternatingcoloursandshapes,attach1rocktoeachrockboardusing1(PB2)1/4x1-1/4”PanBolt(with
lockwasher,atwasherandbarrelnut)and1(S10)#8x1”PanScrewperrock.(g.2.5and2.6)
ThePanScrewisplacedintheholebeneaththePanBolt.(g.2.6)
Note: Make sure all hardware is used to secure each rock properly.
Fig. 2.5
3/16”Flat
Washer
1/4”
BarrelNut
Fig. 2.6
1/4”Lock
Washer
S10
PB2
0630
0631
