Step 20: Lower Slide Wall Assembly
Part 2
C: Tighttothebottomof(2129)CafeSupportandushtooutsideedgesofboth(2153)Postsattach(2155)
SidingNarrowtoeachpostwith2(S0)#8x7/8”TrussScrewsasshowning.20.4and20.6.
D:Tighttobottomof(2155)SidingNarrowandushtotheoutsideedgesofboth(2153)Postsattach4
(2116)Sidingtoeachpostwith2(S0)#8x7/8”TrussScrewsperboard,asshowning.20.4and20.6.
Makesuretherearenogapsbetweenboards.Thebottom(2116)Sidingwillbetighttothetopof(2127)Side
Ground.
E: Frominsidetheassemblyplace(2135)WallSupportoverthecentrepilotholesofthe(2116)Sidingand
(2155)SidingNarrowandtighttothetopofCafeAssemblythenattachfromoutsideoftheassemblywith1
(S0)#8x7/8”TrussScrewpersidingand2(S15)#8x1-3/4”WoodScrewsin(2127)SideGround.(g.20.5
and20.6)
Hardware
Wood Parts
15 x #8 x 7/8” Truss Screw
2 x #8 x 1-3/4” Wood Screw
S0
1 x Siding Narrow 3/8 x 3 x 38-3/4”
4 x Siding 3/8 x 3-1/2 x 38-3/4”
1 x Wall Support 2 x 2 x 22-1/4”
2155
2116
Fig. 20.5
2153
x3perboard
Fig. 20.4
Fig. 20.6
Inside View
Slide Wall
Outside View
S0
2153
2127
2155
2116
2135
Slide Wall
2135
CafeAssembly
CafeAssembly
S15
S15
2129
