16. Graphical display of the measured values
To access the graphical display, go to Menu > Measurement chart
Fixed value
08.03.2015 05:05:06
Measurement chart view.
(sample view with optional chamber equipment)
Press the “Settings” button.
0:0 0:5 0:11 0:16 0:22
Temperature
Objecttemperature
Ou. 1
---------------------------------------------------------------------
Ou. 2
---------------------------------------------------------------------
Ou. 3
---------------------------------------------------------------------
Close
Settings
Home
Fixed value
08.03.2015 05:05:06
Submenu “Settings”.
Select the desired function
and press the operating button.
Settings
Sampling rate
Display range
Parameters
Close Home
16.1 Setting the sampling rate
To define the sampling rate, go to Menu > Measurement chart > Settings > Sampling rate
Fixed value
08.03.2015 05:05:06
Submenu “Sampling rate”.
Select the desired interval
and press the operating button.
Sampling rate
Five seconds
Ten seconds
One minute
Five minutes
Ten minutes
Close Home
