KB / KB-UL (E4 + E6) 10/2021 page 58/147
9.3.7 Switching on or off the optional zero-voltage relay outputs
For chambers equipped with zero-voltage relay outputs (option, chap. 19.5), you can switch on or off the
outputs for each program section via the program editor.
Fixed value
08.03.2015 05:05:06
Time program editor (with option relay outputs)
Select a field under “ ”
and press the operating button.
..\ Temperature controller
[°C]
No.
Value
H:M:S
Ref.
Rep.
T. min
T.max
R/S
1
25.00
00:00:15
1
0
-999.00
999.00
Rampe
Fixed value
08.03.2015 05:05:06
Submenu “Zero -voltage relay outputs”.
The possible combination of switching states are in-
dicated.
Select the desired combination of switching states
and press the operating button.“
[On] = zero-voltage relay outputs turned on
[Off] = zero-voltage relay outputs turned off
..\ Zero -voltage relay outputs
Outputs 1 [Off] 2[Off] 3[Off]
Outputs 1[On] 2[Off] 3[Off]
Outputs 1[Off] 2[On] 3[Off]
Outputs 1[On] 2[On] 3[Off]
Outputs 1[Off] 2[Off] 3[On]
Outputs 1[On] 2[Off] 3[On]
Outputs 1[Off] 2[On] 3[On]
Outputs 1[On] 2[On] 3[On]
Close
A symbol on the controller display indicates the switching state of the three zero-voltage re-
lay outputs as soon as at least one output is switched on (example: outputs 1 + 2 turned on)
9.3.8 Calling up the next parameter
Fixed value
08.03.2015 05:05:06
Time program editor (example).
Press the “Menu” button.
..\ Temperature controller
[°C]
No.
Value
H:M:S
Ref.
Rep.
T. min
T.max
R/S
1
40.00
00:30:00
1
0
-999.00
999.00
Step
2
60.00
01:30:00
1
0
-5.00
5.00
Step
3
80.00
01:00:00
1
0
-5.00
5.00
Step
4
20.00
03:20:00
1
0
-999.00
999.00
Step
5
40.00
00:30:00
1
0
-999.00
999.00
Step
6
60.00
01:30:00
1
0
-5.00
5.00
Step
7
70.00
01:00:00
1
0
-5.00
5.00
Step
8
60.00
01:00:00
1
0
-5.00
5.00
Step
Menu
