Fixed value
08.03.2015 05:05:06
Submenu “Program menu”.
Select “Select parameter”
and press the operating button.
..\ Program menu
Select parameter
Save and exit
Save and run
Exit (without saving!)
Close
With the “Close” button, the controller returns to the time program editor.
Fixed value
08.03.2015 05:05:06
Submenu “Program parameters”.
Select “Fan speed main controller”
and press the operating button.
..\ Program parameters
Temperature controller
Fan speed
Close
Entering the set-point values for another parameter (fan speed)
The number of program lines (program sections) equal to the number in the temperature program is dis-
played. The settings of section length, repeats and the selection „Ramp“ or „Step“ are taken over from the
temperature program; they are no editable in this view. The symbol “ *** ” indicates that there are no toler-
ance value required for the fan speed. You can enter the fan speed set-points.
If you want to insert further sections or perform any other programming, first change back to
the temperature program through Menu > Select parameter > Temperature controller.
Fixed value
08.03.2015 05:05:06
Time program editor (example).
To edit the values, press the operating button, select
the desired value and press the operating button
again.
..\ Fan speed
[%]
No.
Value
H:M:S
Ref.
Rep.
T. min
T.max
R/S
1
100.00
00:30:00
1
0
***
***
Ramp
1
100.00
00:10:00
1
0
***
***
Ramp
1
100.00
00:30:00
2
3
***
***
Ramp
1
100.00
01:00:00
1
0
***
***
Ramp
Menu
