10.3.5 Activity of the shift-point
Fixed value
08.03.2015 05:05:06
Week program editor.
Select a field under “Activity”
and press the operating button.
..\ Temperature controller
[°C]
No.
Value
Day
H:M:S
Activity
1
25.00
Monday
00:00:00
Inactive
Fixed value
08.03.2015 05:05:06
Submenu “Activity“.
Select the desired function
and press the operating button.
..\ Activity
Inactive
Active
Close
10.3.6 Switching on or off the optional zero-voltage relay outputs
Fixed value
08.03.2015 05:05:06
Week program editor
(view with optional control outputs)
Select a field under “
”
and press the operating button.
..\ Temperature controller
[°C]
No.
Value
Day
H:M:S
Activity
1
25.00
Monday
00:00:00
Inactive
Fixed value
08.03.2015 05:05:06
Submenu “Zero -voltage relay outputs”.
The possible combination of switching states are in-
dicated.
Select the desired combination of switching states
and press the operating button.“
[On] = zero-voltage relay outputs turned on
[Off] = zero-voltage relay outputs turned off
..\ Zero -voltage relay outputs
Outputs 1 [Off] 2[Off] 3[Off]
Outputs 1[On] 2[Off] 3[Off]
Outputs 1[Off] 2[On] 3[Off]
Outputs 1[On] 2[On] 3[Off]
Outputs 1[Off] 2[Off] 3[On]
Outputs 1[On] 2[Off] 3[On]
Outputs 1[Off] 2[On] 3[On]
Outputs 1[On] 2[On] 3[On]
Close
A symbol on the controller display indicates the switching state of the three zero-voltage re-
lay outputs as soon as at least one output is switched on (example: outputs 1 + 2 turned on)
