Entering the fan speed setpoint
Fixed value
08.03.2015 05:05:06
Time program editor.
Select a value under “Value”
and press the operating button.
..\ Fan speed
[%]
No.
Value
H:M:S
Ref.
Rep.
T. min
T.max
R/S
1
100.00
00:00:15
1
0
***
***
Ramp
Fixed value
08.03.2015 05:05:06
Entry menu “Fan setpoint”.
A fan speed value is shown. Enter the desired value
with the operating button.
Setting range: 40 % up to 100 %
Press the “Ok” button to confirm.
..\ Fan setpoint
1
00
[%]
1
Pos1 End Ok 0 2 3 4 5 6 7 8 9 ,
Close Ok
When entering a value outside the setting range, the message “invalid value” appears. Press the operating
button to confirm with “Ok” and repeat the entry with a correct value.
9.3.9 Saving the time program and leaving the program editor
Fixed value
08.03.2015 05:05:06
Time program editor (example).
Press the “Menu” button.
..\ Temperature controller
[°C]
No.
Value
H:M:S
Ref.
Rep.
T. min
T.max
R/S
1
40.00
00:30:00
1
0
-999.00
999.00
Step
2
60.00
01:30:00
1
0
-5.00
5.00
Step
3
80.00
01:00:00
1
0
-5.00
5.00
Step
4
20.00
03:20:00
1
0
-999.00
999.00
Step
5
40.00
00:30:00
1
0
-999.00
999.00
Step
6
60.00
01:30:00
1
0
-5.00
5.00
Step
7
70.00
01:00:00
1
0
-5.00
5.00
Step
8
60.00
01:00:00
1
0
-5.00
5.00
Step
Menu
Fixed value
08.03.2015 05:05:06
Submenu “Program menu”.
Select the desired function
and press the operating button.
..\ Program menu
Select parameter
Save and exit
Save and run
Exit (without saving!)
Close
