biosystems PhD Lite User Manual

47
4.7.5 Last calibration
The details of both the last fresh air/zero and the last
span calibration can be viewed by accessing the
LAST_CAL option from the Calibration Menu.
To view the details of the last calibration:
1. Enter the Calibration Menu as described above in
section 4.7.1.
FRESH_AIR REMIND
SPAN_CAL HISTORY
GAS_VALUES
LAST_CAL
IQ LINK EXIT
2. Use the navigation arrows to highlight LAST_CAL
and press the MODE button to confirm the
selection. The details of the last calibration will
then be shown. The right and left navigation arrows
are then used to scroll through the last calibration
details for the various sensors.
O2 LAST CAL
ZERO 11OCT01
→
LEL LAST CAL
ZERO 11OCT01
SPAN 11OCT01 TO 50
MAX ADJUST 92 EXIT
4.7.6 IQ Link
The IQ Datalink System is a data management system
that downloads instrument readings, calibration
information and other data from Biosystems gas
detectors and automatically stores them in a user-
specified database. With the IQ Link function enabled
the PhD Lite will automatically initiate IrDA
communications following a calibration. The instrument
is then placed in front of the PC’s IrDA port and the data
is downloaded into the IQ Database.
1. Enter the Calibration Menu as described above in
section 4.7.1.
FRESH_AIR REMIND
SPAN_CAL HISTORY
GAS_VALUES LAST_CAL
IQ LINK
EXIT
2. Use the navigation arrows to highlight IQ LINK and
press the MODE button to confirm the selection.
The IQ Link setting will then be shown. The up and
down navigation keys are used to change the
enabled/disabled setting.
CONNECT TO IQ LINK
AFTER AUTOCAL
ENABLED
EXIT
↓↑
CONNECT TO IQ LINK
AFTER AUTOCAL
DISABLED
EXIT
3. One the appropriate setting is shown, press the
MODE button to exit.
