BK Precision 2190D User Manual

100
8. Press the “Confirm” button (within five seconds, there
will be a message “Save data success” displayed on the
screen). Now the screenshot image has been saved to
the USB flash drive.
Save/Recall CSV
Table 3.49 – CSV Storage Menu
Option
Setting
Description
Type
CSV
Menu for the Storage .CSV file to USB
flash drive.
Data
Depth
Displayed
Maximum
Set to store displayed waveform data to
.CSV file.
Set to store maximum waveform data
to .CSV file.
Para Save
On
Off
Set whether to include waveform
parameters in the .CSV file or not.
Save
Go to the SAVE ALL interface.

BK Precision 2190D Specifications

General

Brand	BK Precision
Model	2190D
Category	Test Equipment
Language	English
