DCX3000 Switch
724-746-5500 | blackbox.com
Page 8
2.2 Port designations
By default the DCX3000 Switch provides 10 user console ports on its front panel and 20 computer ports along its rear panel,
however, these designations are not fixed. If your installation requires a greater number of computers or has a need for more user
consoles, you can alter the allocation of these standard ports to suit:
Ports 21 to 23 can
be reallocated as
computer ports.
Any of the 20 rear panel computer ports can be reallocated as user console ports
