Blue Giant FMC - PARTS LISTING

Mechanical Dock Leveler – M and FMC Group 12, Section 03, Page 1
Issue Date: 10/01/01, Rev. 0 (Part #038-550E)
PARTS LISTING
ITEM QTY PART NO DESCRIPTION ITEM QTY PART NO DESCRIPTION
1 Safety Skirt Assy
(Right)
23
23
1
4
109-107
013-134
Spring – Lip Lock
Ring - Split
2
SEE PAGE 25
Safety Skirt Assy (Left) 24 1 113-081 Fastener Pin
3 1
CONSULT
FACTORY
Lip Assembly 25 1 200-5001 Maintenance Strut
4 1
SEE CHART
Lifting Arm Assembly 26 3 107-196 Clevis Pin
5 1
SEE CHART
Lip Pusher Shaft 27 1 010-086 Retainer Pin
6 1
SEE CHART
Lip Actuator (Shock) 28 5 011-510 Nut
7 1
SEE CHART
Lip Hinge Shaft 29 6 010-005 Bolt
8 2
111-572
Adjustment Block 30 4 011-511 Jam Nut
9 2 788-085 Pin Assy – Adjusting
Block
31 7 013-012 Spring Pin
10 1 793-965 Dog Assy – Lip Lock 32 5 013-010 Spring Pin
11 2 114-663 Clevis 33 2 013-018 Cotter Pin
12 1 788-176 Pin Assy – Lifting Arm 34 2 105-879 Spacer Washer
13 1 788-197 Pull Chain Assembly 35 2 010-122 Pin
14 1 788-037 Hold Down Box Assy 36 2 012-274 Spacer Washer
15 1 203-5011 Float Spring Assembly 37 3 011-554 Nylock Nut
16 1 111-929 Spring – ‘A’ Series 38 4 011-082 Drive Screw
16 1 223-0005 Spring – ‘C’ Series 39 1 011-543 Nut
17 -- 223-0004 Main Lift Spring 40 6 012-211 Flat Washer
18 2 111-570 Adjustment U-Bolt 41 -- 038-009 Safety Striping
19 2 793-092 Cable Roller Assembly 42 2 106-389 Spacer Washer
20 1 109-791 Roller-Lifting Arm 43 3 018-501 Bushing
21 1 223-0000 Axle – Roller
NOT
SHOWN
2 110-886 Dock Bumper – DB13
22 2 018-500 Bearing - Roller
Model Item #4 Item #5 Item #6 Item #7
25,000 Cap
Item #7
30,000 Cap
A586M 788-603 109-391 793-375 - - - - 100-452
A686M 788-603 109-391 793-375 - - - - 100-453
A688M 788-604 109-391 793-375 - - - - 100-453
A6810M 788-605 109-390 793-374 - - - - 100-453
A6812M 788-606 109-437 793-375 - - - - 100-453
A6686M 788-603 109-391 793-375 - - - - 113-643
A6688M 788-604 109-391 793-375 - - - - 113-643
A66810M 788-605 109-390 793-374 - - - - 113-643
A66812M 788-606 109-437 793-373 - - - - 113-643
A786M 788-603 109-391 793-375 - - - - 109-363
A788M 788-604 109-391 793-375 - - - - 109-363
A7810M 788-605 109-390 793-374 - - - - 109-363
A7812M 788-606 109-437 793-373 - - - - 109-363
FMC6-6 788-603 109-391 783-288 100-453 109-699
FMC6-8 788-604 109-391 783-288 100-453 109-699
FMC66-6 788-603 109-391 783-288 113-643 109-687-1
FMC66-8 788-604 109-391 783-288 113-643 109-687-1
FMC7-6 788-603 109-391 783-288 109-363 109-690
FMC7-8 788-604 109-391 783-288 109-363 109-690
