Blue Giant FMC - Service and Repair

Mechanical Dock Leveler – M and FMC Group 08, Section 01, Page 1
Issue Date: 10/01/01, Rev. 0 (Part #038-550E)
Service and Repair
Mechanical Dock Leveler
Index
SUBJECT GROUP SECTION PAGE
Index 08 01 1
Hold Down Box and Components:
Lock Roller and Wear Strip Replacement 08 02 1 – 2
Hold Down Box Assembly Replacement 08 03 1 – 3
Hold Down Cable Replacement 08 04 1 – 4
Rewind Spring Replacement 08 05 1 - 4
Rewind Wheel Replacement 08 06 1
Repair Kit – Parts 08 06 1
Float Spring and Cable Roller Replacement 08 07 1 - 2
Lip Lock and Spring Assembly Replacement 08 08 1 – 2
Lip Actuator Replacement 08 09 1 – 4
Cam Roller Replacement 08 10 1 – 2
Lift Springs, Lifting Arm, Adjusting Blocks,
Adjusting ‘U’ Bolts Replacement
08 11 1 - 3
Lip and Lip Hinge – Inspection and Diagnosis 08 12 1 - 2
Lip Replacement – Choice of Methods 08 13 1
Lip Replacement – Method No. 1 08 13 2
Lip Replacement – Method No. 2 08 13 3 - 4
Lip Replacement – Method No. 3 08 13 5
Lip Replacement –Method No. 4 08 13 6 - 11
Lip Crown Modification – Decreasing Crown 08 14 1 - 3
Lip Crown Modification – Increasing Crown 08 15 1 - 3
Increasing Lip Length and / or Thickness 08 16 1
Longer Lip Requirement – Move Deck Forward 08 17 1 - 7
Replacement Parts Listing – Index
12 01 1
Installation Instructions – Cover Page 14 01 1
Installation Instructions - Index
14 01 2
Maintenance and Lubrication 16 01 1 – 2
Lubrication 18 01 1
