BONFIGLIOLI Vectron Agile Series User Manual

Probus DP V1 Agile 06/201036
Handling of the Objects
16.3.2 Profibus Output Sources (OUT-PZD x)
The table below lists the available output sources of the PZD Out objects. The content of the sources
depends on the application. For the different
data types the equivalent sources must be connected to
the inverter input parameters.
Note: − The availability of Out sources depends on the number of configured PZD objects.
− Every configured PZD object consists of either two Boolean, two word or one long
output object.
−
One PZD out object can be used for one data type only (depending on the application
requirements).
− The first configured PZD object (mandatory) represents the PZD1/2 with fixed
contents and functions.
No. of
configured
PZD Objects
Boolean Sources Word Sources Long Sources
Name Source
No.
Name Source
No.
Name Source
No.
2 Out-PZD3 Boolean 640 Out-PZD3 Word 656 Out-PZD3/4 Long 672
Out-PZD4 Boolean 641 Out-PZD4 Word 657
3 Out-PZD5 Boolean 642 Out-PZD5 Word 658 Out-PZD5/6 Long 673
Out-PZD6 Boolean 643 Out-PZD6 Word 659
4 Out-PZD7 Boolean 644 Out-PZD7 Word 660 Out-PZD7/8 Long 674
Out-PZD8 Boolean 645 Out-PZD8 Word 661
5 Out-PZD9 Boolean 646 Out-PZD9 Word 662 Out-PZD9/10 Long 675
Out-PZD10 Boolean 647 Out-PZD10 Word 663
6 Out-PZD11 Boolean 648 Out-PZD11 Word 664 Out-PZD11/12 Long 676
Out-PZD12 Boolean 649 Out-PZD12 Word 665
7 Out-PZD13 Boolean 650 Out-PZD13 Word 666 Out-PZD13/14 Long 677
Out-PZD14 Boolean 651 Out-PZD14 Word 667
8 Out-PZD15 Boolean 652 Out-PZD15 Word 668 Out-PZD15/16 Long 678
Out-PZD16 Boolean 653 Out-PZD16 Word 669
9 Out-PZD17 Boolean 654 Out-PZD17 Word 670 Out-PZD17/18 Long 679
Out-PZD18 Boolean 655 Out-PZD18 Word 671
Note: − Every source can be connected to an inverter input parameter with the same data
type. This method is the same as used with Systembus receive objects.
− Boolean sources are representatives for Boolean objects.
− Word sources are representatives for current or torque objects.
− Long sources are representatives for frequency or position objects.
