Probus DP V1 Agile 06/201038

Handling of the Objects

Note: The displayed "PDP active current" depends on the control system. In field-

orientation,

the torque-

forming current is displayed, in applications with a v/f characteristic control,

the active current, which is also a measure for the torque.

The “PDP absolute current” (r.m.s. current) is always positive. Active current and torque-

forming current have a sign prefixed.

Positive currents = motor

Negative currents = generator operation.

Current Scaling

Standardization

Reference value Binary Decimal Hexadecimal

+ 100% + 2

16384 0x4000

The possible range = ±200% = +32768 to -32768 = 0x8000 to 0x7FFF

For the internal scaling, the data set change-over capable parameter

Rated current

371

is used as a

reference.

Parameter Setting

No. Description Min. Max. Factory Setting

371 Rated Current 0,01 · I

FUN

10 · I

FUN

BONFIGLIOLI Vectron Agile Series User Manual
