Probus DP V1 Agile 06/201042
Handling of the Objects
The Status Word reflects the operation state.
Status Word
State HEX (*) Bit 6 Bit 5 Bit 3 Bit 2 Bit 1 Bit 0
Switched On 0x23 0 1 0 0 1 1
Fault 0x08 0 x 1 0 0 0
(*) without considering bits 7 to bit 15
Note: The occurrence of a fault leads to a switch-over to the "Fault" state.
Bit 7 "Warning" can be set at any time. It indicates a device-
internal warning message. The
evaluation of the present warning is carried out by reading out the warning status with Parameter
Warnings
270.
Bit 9 "Remote" is always = 0.
Bit 10 "Reference value reached" is set whenever the specified refer
ence value has been reached.
In the special case of power failure regulation, the bit is also set if the power failure regulation has
reached the frequency 0 H
z (see operating instructions). For "Reference value reached“ there is a
hysteresis (tolerance range), which can be set via parameter Reference Value Reached: Hysteresis
549 (see operating instructions).
Bit 11 "Limit value reached"
indicates that an internal limit is active. This can, for example, be the
present current limit, the torque limit or the over-
voltage limit. All the functions lead to the reference
value being quit or not reached.
Bit 15 "Warning 2" indicates a warning which leads to a fault switch-
off of the frequency inverter
within a short period of time. This bit is set if there is a warn
ing for motor temperature, heat
sink/inside temperature, Ixt monitoring or mains phase failure.
