Maintenance | BAT 430 | 19 en
5. Maintenance
! Work on electrical equipment is only to be per-
formed by persons with sufficient knowledge and
experience of electrical systems!
5.1 Cleaning
! Do not use abrasive cleaning agents and coarse
workshop cloths!
¶ The housing and the LCD are only to be cleaned us-
ing a soft cloth and neutral cleaning agents.
5.2 Spare and wearing parts
Description Order number
Charging lead with PVC-insulation
<)
1 684 460 275
Mains connecting cable 2,5 m
<)
1 684 461 168
<)
Wearing parts
5.3 Disposal
The BAT 430 is subject to the European
directive 2002/96/EC (WEEE).
Dispose of used electrical and electronic
devices, including cables, accessories and
batteries, separately from household waste.
¶
Make use of the local return and collection
systems for disposal.
¶ Proper disposal of the BAT 430 prevents
environmental pollution and possible
health hazards.
6. Technical data
Property Value, Range
Charging current
Maximal 30 A
Charging lead length
*)
2 m
Charging lead cross-section 6 mm
2
Power consumption 900 W
Weight 5 kg
Characteristic charging curve IUIaIaI
Final charge voltage at setting >
15 °C
14,0 V / 28,0 V
Voltage limit for secondary charg-
ing at setting > 15 °C
14,4 V / 28,8 V
Final charge voltage at setting <
15 °C
14,4 V / 28,8 V
Voltage limit for secondary charg-
ing at setting < 15 °C
14,8 V / 29,6 V
Back up
Buffer mode
12,0 V / 24,0 V maximal 2 A
13,5 V / 27,0 V maximal 30 A
Function temperature range 0 °C bis 40 °C
Mains voltage / frequency 230 V, 50/60 Hz
Mains fuse H 250 T 6,3 A
Nominal battery voltage 12 V / 24 V
Protection type (DIN 40050) IP 20
Class of protection (DIN 40530) II
Dimensions (W x H x D) 260 x 160 x 250 mm
Work-related
noise emission value (Lpa)
≤ 70 dB(A)
Interference emission level DIN 40839 Interference
emission level I
*)
The charging leads may not be changed!
