Bosch Cookit - Symbols

en Familiarising yourself with your appliance
96
1
Measuring cup
2
Inner lid
3
Cover for outer lid
4
Outer lid with seal
5
XL pot with Smart Sensor
technology
6
Lid lock
7
Main unit with built-in scales
8
LED temperature indicator
9
Controls
10
SensorSpot
11
Spring washer
12
Tool holder with silicone seal
ring
13
Threaded ring with wings and
shaft spring
14
Contact pins
15
Lid catch
16
Drain hole
17
Contact point
18
Infrared temperature sensor
19
Drive
20
Vent grille
21
Power cord storage compart-
ment
22
Rating plate
5.2 Symbols
You can find an overview of the sym-
bols on your appliance here.
Appliance symbols and tool symbols
Sym-
bol
Explanation
Universal knife
3D stirrer
Twin whisk
Drive shaft for shredding
discs
Maximum quantity
Minimum capacity for steam-
ing
Cleaning position
Suitable for contact with
food
Dishwasher-proof
Position markings
Locking mechanism
Open locking mechanism.
Close locking mechanism.
Open cover for outer lid.
Close cover for outer lid.
Release position
Locking position
Lid holder
Read user manual.
Do not reach into the feed-
ing tube.
Display symbols
Sym-
bol
Explanation
Time counts down.
Time counts up.
Lid lock mechanism is act-
ive.
View the following recipe
steps.
