Clause / Requirement Compliance Signature
Where an alphanumeric display is used
to display indications relating to
different functional conditions these
may be displayed at the same time.
However, for each functional condition
there shall be only one window, in
which all of the information relating to
that functional condition is grouped.
The front panel of the controller and
remote control panels have a field
with LEDs that have specific fault
assigned to them. Each zone has a
separate LED to signal a fault in that
zone.
If a zone on a router is in fault
condition. The main controller will
signal a router fault and the router
will indicate which zone.
The logging application delivered
with the Plena Voice Alarm System
offers a graphical user interface for
viewing events (Logging Viewer).
5.4 Indication of the supply of power Plena Voice Alarm System is
compliant.
5.4.1 A visible indication shall be given
by means of a separate discrete light-
emitting indicator while the VACIE is
supplied with power.
Each Plena Voice Alarm System
component has a dedicated power
LED.
5.4.2 Where the VACIE is distributed in
more than one cabinet, an indication of
supply of power to each distributed
cabinet shall be given at that point.
The Plena Voice Alarm System can
be distributed in more than one
cabinet, depending on the
installation of the system. Many
system components can be mounted
in a 19’’ rack. Each cabinet will
indicate supply of power
independently if the system is
distributed in more than one
cabinet.
5.5 Additional indications Plena Voice Alarm System is
compliant.
Where additional indications are
provided, they shall be clearly
identifiable and shall not override the
primary indication of the VACIE.
For LEDs with multiple indication
functions, all of the additional
indications are clearly identified (in
the Installation and User Instructions
of the Plena Voice Alarm System);
since the fault warning indication
and the voice alarm indication
always have precedence over the
additional indications, the primary
indications are not overridden.
Almost all LEDs indicate a single
function.
