Solution 6000
Installation Manual Comms Programming
9-20
Bosch Security Systems 07/14 BLCC610I
Comms > IP Reporting >
ACK Wait Time
MENU 5-6-3
0 1 0
Seconds
This menu allows the installer to program the
acknowledge wait time in seconds for both Destination 1
and/or Destination 2. The acknowledge wait time can be
programmed between 1 and 255 seconds (0 = Disabled).
1) Press [MENU] + [5] + [6] + [3]. The keypad will
prompt you to select which destination
(destination 1 or 2) that you want to program the
acknowledge wait time.
Rr1 Dest 1
Rr2 Dest 2
Exit
Press
OK or MENU
2) Highlight the destination number (1 or 2) required,
then press [OK]to select.
3) The keypad will display the current acknowledge
wait time.
Ack Wait Time Rr1
010 Seconds
Press 0-9 OK to SAVE
4) Use the numeric keys [0] to [9] to program the new
acknowledge wait time in seconds (000 to 255),
then press [OK] to save and exit or press [MENU] to
exit without saving.
Comms > IP Reporting >
IP Format
MENU 5-6-4
00 - Conettix 0 1
01 - Conettix NNC (Anti Replay)
02 - CSV IP ALARM
03 - Suretek (TBA)
04 - Permacom (TBA)
05 - Direct Wireless (TBA)
06 - MyAlarm CID (TBA)
This menu allows the installer to program which IP format
the control panel will report to the base station receiver.
1) Press [MENU] + [5] + [6] + [4]. The keypad will
prompt you to select which destination
(destination 1 or 2) that you want to program the
acknowledge wait time.
Rr1 Dest 1
Rr2 Dest 2
Exit
Press
OK or MENU
2) Highlight the destination number (1 or 2) required,
then press [OK]to select.
3) The keypad will display the current IP format.
IP Format Rr1
01 - Conettix NNC
Press
0-9 OK to SAVE
4) Use the numeric keys [0] to [9] to program the new
IP format required, then press [OK] to save and exit
or press [MENU] to exit without saving.
Comms > IP Reporting >
Retry Count
MENU 5-6-5
0 3
This menu allows the installer to program the number of
attempts that the system will try to communicate via TCP/
IP to the base station receiver for both Destination 1 and/
or Destination 2. The retry count can be programmed
between 01 and 15 (00=Disabled).
1) Press [MENU] + [5] + [6] + [5]. The keypad will
prompt you to select which destination
(destination 1 or 2) that you want to program the
acknowledge wait time.
Rr1 Dest 1
Rr2 Dest 2
Exit
Press
OK or MENU
2) Highlight the destination number (1 or 2) required,
then press [OK]to select.
The keypad will display the current retry count.
Retry Count Rr1
3
Press 0-9 OK to SAVE
3) Use the numeric keys [0] to [9] to program the new
retry count, then press [OK] to save and exit or
press [MENU] to exit without saving.
Comms > IP Reporting >
Encryption Key
MENU 5-6-6
Dest Nº 1
1 Digits 32
0 0 0 0 0 0 0 0 0 0 0 0 0
Dest Nº 2
1 Digits 32
0 0 0 0 0 0 0 0 0 0 0 0 0
The encryption key must match the encryption key on the
base station receiver for communication to take place. To
To Next Page
